951760 - PKG,SWX-ZF-S, FEB-1 BLOWER / SA-W810-ZF-WM

Miller® FILTAIR® SWX-S (Self-Cleaning Filter) Single-Arm Package, 10 ft. ZoneFlow™ Arm

Wall or column mounted fume extraction system designed specifically for welding. This powerful high volume system features ZoneFlow™ technology creating a much larger capture area than existing source-capture products and minimizes arm interactions. This system is ideal for fabrication shops and manufacturing environments.

ZoneFlow™ Technology: Creates a negative pressure zone that funnels air to the center of the arm from greater distances, up to 5 feet away. Both the Capture 5 extraction arm and machine are needed for these results (arm sold separately). Easy-to-Operate ZoneFlow™ Arm: Arm with external adjustments so air can pass through with less airflow resistance, giving you stronger CFM (airflow). It offers reliable and accurate positioning across the full range of motion of the arm, as well as easy adjustment and maintenance to ensure long-lasting operation. Extraction arms are available in 10- or 12-foot lengths. Less Arm Movement: With a capture zone that is 3 times larger than traditional systems, users have less interaction with the arm, increasing arc-on time and productivity. FilTek® XL Filter Technology: FilTek XL Filter Technology is specifically designed for welding fumes. This technology offers a longer filter life - up to 2 times that of treated cellulous filters and superior filtering of up to 95% of weld fume particulate. Self-Cleaning Filter Model: Ideal for high arc-on time environments the self-cleaning filter model is designed to capture weld fume particulate with a cleanable filter and safety deposit them in an integrated particle bin, the self-cleaning model provides unrivaled filtering performance. MERV 15 Filter Rating: Filters are rated on a MERV scale, which measures filter efficiency based on particle count. MERV ratings range from 1-16, with 16 being the best at filtering small particles-such as those found in weld fumes. One Minute Cleaning Cycle: The one-minute filter cleaning cycle is as easy as the push of a button on the control panel. Latches release a disposal drawer allowing it to slide out to provide easy and convenient access to empty out the collected particles. (Compressed air is required to operate this cleaning mechanism) Class Leading Suction Power: High-performance fan generates 1,200 cfm and creates an Accu-Rated minimum of 875 cfm extraction at the hood to better capture weld fumes and provide a cleaner environment. Dual Fan Capture Zone: Keep both sides of the fans turned on for a 360 degree capture zone or turn one side off to position next to a wall or curtain for a 180 degree capture zone. FILTAIR® SWX System Arm Add-On Packages: Easy to order and allow the flexibility to mix different arm types to solve various fume extraction challenges (See Accessories).
