The Victor® VTS 710 Series Two Stage Heavy-Duty Acetylene Regulator is designed for applications that require precise and constant outlet pressure, with a high flow rate of up to 8,000 SCFH. This regulator has a delivery range of 2-15 psig and a maximum inlet pressure of 3000 psig.
Made with a die-forged brass body and spring housing cap, this regulator is built for strength and durability. It features a gauge with a 400 inlet gauge range and a 30 outlet gauge range. The stainless steel diaphragm ensures accurate and long-lasting service.
The regulator has a 510 CGA inlet connection and 7/8"-14 LH(M) outlet connections. It is specifically designed for applications that require accurate and uniform outlet pressures. With a flow coefficient of 0.244 Cv, it offers precise flow control.
The regulator comes with a brass adjusting screw with a forged T-handle, a Delrin insert bushing for durability and easier adjusting, and a stainless ball in the key for easy adjustment. The adjusting spring is pretested for quality assurance, and the precision-machined nozzle provides maximum flow control.
The stem-type seat mechanism and external self-reseating relief valve ensure proper sealing and safety.
Please note that the regulator will deliver at least the stated upper range, and in some cases, it may exceed the stated upper range. The sintered inlet filter is electroless nickel plated bronze, ensuring efficient filtration.
| Additional Information |
|---|
| Packaging Description:pack of 1 |
| Item:Regulator |
| Brand:Victor |
| Used On Which Gas:Acetylene |
| CGA Fitting:cga510 |
| Max Inlet:300psi |
| Max Outlet:15psi |
