The Victor® VTS 250 Series Two Stage Medium Duty Methane/Hydrogen Regulator is a reliable and durable option for applications requiring a consistent delivery pressure across varying inlet pressures. With a delivery range of 2 - 40 psig and a maximum inlet pressure of 3000 psig, this regulator is designed to provide accurate and uniform outlet pressures for medium to high capacity general-purpose applications.
Featuring a die-forged brass body and spring housing cap, the regulator is built to withstand tough conditions. The 2" steel gauges with a 4000 inlet gauge range and 60 outlet gauge range provide precise readings. The 1.3" and 1 3/4" fabric reinforced neoprene diaphragm ensures long-lasting and precise service.
The regulator is equipped with an electroless nickel plated bronze sintered inlet filter and a stem-type seat mechanism inlet pressure for effective sealing and flow control. A self-reseating relief valve is also included, offering additional safety.
Measuring 6 1/2" X 6.13" X 5.63", the regulator delivers at least the stated upper range and can exceed it in some cases.
Please note that this regulator does not include a relief valve to protect downstream equipment. The Victor® VTS 250 Series Two Stage Medium Duty Methane/Hydrogen Regulator is a reliable and efficient choice for various applications.
| Additional Information |
|---|
| Packaging Description:pack of 1 |
| Item:Regulator |
| Brand:Victor |
| Used On Which Gas:Methane/Hydrogen |
| CGA Fitting:cga350 |
| Max Inlet:NA |
| Max Outlet:40psi |
