The Victor® SR4F Single Stage Heavy-Duty High Pressure Carbon Dioxide Piston Regulator is designed to deliver pressure ranging from 50 to 750 psig, making it ideal for pressure vessel and dead-end testing purposes. This regulator is equipped with a machined brass body and a housing cap, ensuring durability and reliability. It also features two 2 1/2" brass gauges with a brass piston and a Delrin cap bushing, allowing for smooth adjustments. The regulator comes with a 320 CGA inlet connection that includes a bronze sintered filter, as well as 5/8" - 18 UNF outlet connections with a 1/4' stainless tube fitting. Measuring 6" X 6 1/4" X 6 1/2", this regulator boasts a cartridge type seat assembly with a PCTFE seat and an external adjustable relief valve. Other noteworthy features include piston type actuation brass, an external adjustable relief valve (F and G range model), and ventable relief valves (for hydrogen models, except for J Series). Additionally, it is equipped with a sintered inlet filter in bronze.
| Additional Information |
|---|
| Packaging Description:pack of 1 |
