The Victor® ETS4 EDGE™ Series Two Stage High Capacity Carbon Dioxide Regulator is perfect for applications that require a precise and constant outlet pressure. This regulator has a delivery range of 5-125 psig and a maximum inlet pressure of 3000 psig, ensuring reliable performance.
The regulator is constructed with a forged brass body, zinc-aluminum housing caps, and a high impact ABS gauge guard. It also features a 2.7" fabric reinforced neoprene diaphragm for durability. The compact layout includes built-in gauges that are recessed into the body for protection.
With a 320 CGA inlet connection and a CGA 032 5/8" - 18 UNF outlet connection, this regulator is designed for easy use. The advanced design combines both form and functionality. The color-coded knobs and easy-to-read gauges with enhanced graphics allow for quick gas identification.
The regulator's user-friendly architecture includes a side mounted knob for natural and safe hand/body positioning when adjusting the delivery pressure. A single impact point helps safeguard critical system elements, ensuring system integrity.
Additional features of this regulator include an external self-reseating relief valve, a stem type seat mechanism, and a nickel plated bronze sintered inlet filter. The color-coded SLAM™ impact absorbing safety knob provides added strength, safety, and protection for the regulator internals.
This regulator comes with a five-year warranty and meets or exceeds CGA E-4, UL 252, and ASTM G-175 promoted ignition test standards. Its brass adjusting screw with forged T-Handle, Delrin insert bushing, and die-forged brass spring housing cap provide durability and ease of adjustment. The stainless steel diaphragm ensures accurate and long-lasting service, while the stainless ball in the key allows for easy adjustment. The regulators are pretested for quality assurance, and the precision machined nozzle ensures optimum flow control. Rest assured, these regulators will deliver at least the stated upper range, and in some cases, may even exceed it.
| Additional Information |
|---|
| Packaging Description:1 per each |
| Item:Regulator |
| Brand:Victor |
| Used On Which Gas:CO2 |
| CGA Fitting:cga320 |
| Max Inlet:NA |
| Max Outlet:125psi |
