The Victor® HVTS 2570 Two Stage Medium Duty Argon, Argon/CO2, Helium Calibrations Regulator And Flow meter Combination is designed for MIG or TIG applications. This regulator offers a delivery range of 20 - 150 SCFH and is perfect for precise gas flow control. With a maximum inlet pressure of 3000 psig, the regulator features a durable forged brass body with a housing cap. The 2" high pressure gauges are equipped with a fabric reinforced neoprene diaphragm for reliable performance. The regulator is equipped with a bronze sintered filter on its 580 CGA inlet connection, ensuring long-lasting service. Its 5/8"-18 RH(F) outlet connection guarantees a secure and efficient gas flow. This compact regulator is 7" X 6 1/2" X 5 1/2" in size and provides extremely accurate flow rates while reducing cylinder pressure. It has a preset low surge outlet pressure of 25 psig. Featuring a stem type seat mechanism and an external reseating relief valve, this regulator is built to deliver consistent gas flow. It is an ideal choice for MIG/TIG applications.
| Additional Information |
|---|
| Packaging Description:pack of 1 |
| Item:Flow Regulator |
| Brand:Victor |
| Used On Which Gas:Argon or Weldmix |
| CGA Fitting:cga580 |
| Max Inlet:NA |
| Max Outlet:120ft3/hr |
