The Victor® HVTS 2537 Two Stage Medium Duty Argon/Helium Calibrations Regulator And Flow meter Combination is designed for MIG or TIG applications. It offers a delivery range of 15 - 65/40 - 200 SCFH and is highly reliable. The regulator has a maximum inlet pressure of 3000 psig and is made of high-quality forged brass body with a housing cap. It features 2" high pressure gauges with a fabric reinforced neoprene diaphragm. The regulator comes with a 580 CGA inlet connection, including a bronze sintered filter, and a 5/8"-18 RH(F) outlet connection for long-lasting service. It is equipped with an external reseating relief valve and a stem type seat mechanism with 2 gas calibrations. This two-stage regulator is compact in size, measuring 7" X 6 1/2" X 5 1/2", and offers precise flow rates while reducing cylinder pressure. It has a preset low surge outlet pressure of 25 psig. With its durable forged brass body and housing cap, fabric reinforced neoprene diaphragm, stem type seat mechanism, and accurate gas flow regulation, this regulator is suitable for various MIG and TIG applications.
| Additional Information |
|---|
| Packaging Description:pack of 1 |
| Item:Flow Regulator |
| Brand:Victor |
| Used On Which Gas:Argon or Weldmix |
| CGA Fitting:cga580 |
| Max Inlet:NA |
| Max Outlet:60ft3/hr |
