The Victor® HSR Series Single Stage Medium Duty Hydrogen Flow Meter Regulator is designed for MIG/TIG applications and offers a delivery range of 5 - 40 psig. This regulator is made with a die-forged brass body, ensuring strength and durability. It features a 2" high pressure gauge and has a 350 CGA inlet connection with a 9/16"-18 LH(M) outlet connection.
With a maximum inlet pressure of 3000 psig, this regulator is equipped with a fabric reinforced neoprene diaphragm, providing precise and long-lasting service. It also includes a bronze sintered inlet filter and a stem-type seat mechanism for optimal sealing. The external self-reseating relief valve adds an extra layer of safety.
Measuring 7" X 4 1/4" X 6 1/4", this compact regulator delivers at least the stated upper range and may even surpass it in some cases. It is designed for accurate gas flow and is perfect for MIG/TIG applications.
| Additional Information |
|---|
| Packaging Description:pack of 1 |
| Item:Flow Regulator |
| Brand:Victor |
| Used On Which Gas:Methane/Hydrogen |
| CGA Fitting:cga350 |
| Max Inlet:NA |
| Max Outlet:38ft3/hr |
