The Victor® ETS4 EDGE™ Series Two Stage High Capacity Oxygen Regulator is a reliable and precise tool for applications that require constant outlet pressure. With a delivery range of 2-40 psig and a maximum inlet pressure of 3000 psig, this regulator offers consistent performance.
The regulator features a forged brass body, zinc-aluminum housing caps, and a high impact ABS gauge guard. Its compact layout includes recessed gauges for added protection. The 1 1/2" UL listed/recognized gauges have a range of 4000 psig for the inlet gauge and 60 psig for the outlet gauge.
Designed with user-friendliness in mind, the regulator has color-coded knobs for quick gas identification and a side-mounted knob for easy pressure adjustment. It also includes a single impact point to safeguard critical system elements.
The regulator's advanced design ensures uniform flow performance over a variety of cylinder pressures, delivering high sensitivity and accuracy in pressure delivery. It is equipped with a self-reseating relief valve, stem type seat mechanism, and a nickel plated bronze inlet filter for enhanced durability.
For added strength and protection of the internal components, the regulator comes with a color-coded SLAM™ impact absorbing safety knob. It measures 6.85" X 4.72" X 4.4" and is backed by a five-year warranty.
This regulator meets or exceeds CGA E-4, UL 252, and ASTM G-175 standards, ensuring safety and reliability. Its brass adjusting screw with forged T-Handle and Delrin insert bushing, die forged brass spring housing cap, stainless steel diaphragm, and precision machined nozzle contribute to its durability and optimum flow control.
| Additional Information |
|---|
| Packaging Description:pack of 1 |
| Item:Regulator |
| Brand:Victor |
| Used On Which Gas:Argon or Weldmix |
| CGA Fitting:cga580 |
| Max Inlet:NA |
| Max Outlet:40psi |
