0781-5224 - ETS4-125-590 EDGE TWO STAGE REG - INDUST

The Victor® ETS4 EDGE™ Series Two Stage High Capacity Industrial Air Regulator is perfect for applications that require precise and consistent outlet pressure. With a delivery range of 5 - 125 psig and a maximum inlet pressure of 3000 psig, this regulator delivers reliable performance.

Featuring a forged brass body, zinc-aluminum housing caps, and a high impact ABS gauge guard, this regulator is built to last. The 2.7" fabric reinforced neoprene diaphragm ensures durability and long-lasting service.

The regulator comes with 1 1/2" UL listed/recognized gauges, with a 4000 inlet gauge range and 400 outlet gauge range. The compact layout includes built-in gauges that are recessed into the body for added protection.

Designed with user-friendliness in mind, this regulator has color-coded knobs for quick gas identification. The side-mounted knob allows for natural and safe hand/body positioning when adjusting the delivery pressure.

Safety is a priority with this regulator, as it has a single impact point that helps safeguard critical system elements. It also includes an external self-reseating relief valve, a stem type seat mechanism, and a nickel-plated bronze sintered inlet filter.

With a 0.488 Cv flow coefficient, this regulator delivers uniform flow performance across a range of cylinder pressures. The easy-to-read gauges have enhanced graphics for clear visibility.

Measuring 6.85" X 4.72" X 4.4", this regulator comes with a five-year warranty. It meets or exceeds CGA E-4, UL 252, and ASTM G-175 promoted ignition test standards.

This regulator is designed for durability, with features like a brass adjusting screw with a forged T-handle, a Delrin insert bushing for easier adjusting, and a die-forged brass spring housing cap for greater strength. The stainless steel diaphragm ensures accurate and long-lasting service.

Overall, this regulator provides high sensitivity and accuracy in delivery pressure, making it a reliable choice for industrial applications. It will deliver at least the stated upper range and in some cases may even exceed it.
