0781-5231 - ETS4-125-346 EDGE TWO STAGE REG - AIR

Packaging: pack of 1

Sorry, product has been discontinued by the vendor.

OVERVIEW

The Victor® ETS4 EDGE™ Series Two Stage High Capacity Air Regulator is designed for applications that require precise and consistent outlet pressure. It offers a delivery range of 5 - 125 psig and has a maximum inlet pressure of 3000 psig, ensuring reliable performance.

This regulator features a forged brass body, zinc-aluminum housing caps, and a high impact ABS gauge guard for durability. The 2.7" fabric reinforced neoprene diaphragm adds to its strength.

With its compact layout, this regulator has recessed gauges that are built into the body for protection. The 1 1/2" UL listed/recognized gauges have a range of 4000 for the inlet and 400 for the outlet.

The advanced design of this regulator blends form and functionality. The easy-to-read gauges have enhanced graphics and color-coded knobs for quick gas identification. The side-mounted knob allows for natural and safe hand/body positioning when adjusting the delivery pressure.

Safety is a priority with this regulator. It features a single impact point configuration to safeguard critical system elements. The regulator also includes an external self-reseating relief valve, a stem type seat mechanism, and a nickel-plated bronze sintered inlet filter.

For added strength and protection, the regulator comes with a color-coded SLAM™ impact absorbing safety knob. It measures 6.85" X 4.72" X 4.4" and comes with a five-year warranty.

This regulator meets or exceeds CGA E-4, UL 252, and ASTM G-175 promoted ignition test standards. Its brass adjusting screw with forged T-Handle and Delrin insert bushing ensure durability and easier adjusting. The die-forged brass spring housing cap provides greater strength and durability.

The stainless steel diaphragm offers accurate and long-lasting service, while the stainless ball in the key allows for easy adjustment. The adjusting spring has been pretested for quality assurance. The sintered inlet filter is electroless nickel plated bronze for enhanced performance.

With a precision machined nozzle for optimum flow control, this regulator delivers uniform flow performance over a wide range of cylinder pressures. It provides high sensitivity and accuracy in delivery pressure. Please note that the regulators may deliver at least the stated upper range and in some cases may exceed it.
Additional Information
Packaging Description:pack of 1
Item:Regulator
Brand:Victor
Used On Which Gas:n/a
CGA Fitting:cga346
Max Inlet:NA
Max Outlet:125psi

APPLICATIONS

  • Industrial and General Fabrication
  • Light Fabrication
  • Repair and Maintenance
  • Structural Steel Fabrication
